Drag the Application component onto the Diagram to the bottom left of the intersection.In the Component Library panel, in the Target Library, locate the Application component ( ).Remove the Counter ( ) and both Formula ( ) components.Download the initial project files to get started.The starting point of this tutorial is the traffic light model of the previous tutorial. Defining a simulation interface for the C-code program The program will be developed and tested by coupling it to the simulation model of the traffic lights in Studio Technix. The predefined light sequence will be replaced by a custom program in C. The starting point of this tutorial is the Traffic Light Model project of the Traffic Light Model tutorial. The controller is an application written in C-code that determines the state of the traffic lights based on a sensor that detects whether cars are present or not. In this tutorial you will create a controller for traffic lights at an intersection. Note: these docs are for the alpha version of Studio Technix (Released May 2021).ĭocumentation will be updated when the early-adopter program becomes public.
